Capsule Filling
Small Batch Capsule Filling Machine
The CF-S 120C is specifically designed for research and development requirements where small batches are produced.
THE APPLICATION
Equipment overview.
The CF-S 120C is specifically designed for research and development requirements where small batches are produced.
EQUIPMENT INFORMATION
Technical details.
Confirm the model, utilities and configuration for your project with our team.
Technical specifications
| Model | CF-S 120C |
|---|---|
| Filling dosage form | Powder or pellets |
| Capsule size | 00#–5# and safety capsule A–E |
| Maximum output | 7,200 capsules/hour |
| Motor power | 0.7 kW |
| Power supply | AC 220 V; 50 Hz |
| Noise | ≤75 dBA |
| Compressed air | 8 m³/h; 0.4–0.6 MPa |
| Dimensions | 730 × 700 × 1500 mm |
| Weight | 140 kg |
Source: manufacturer specification sheet, page 2 (PDF). Confirm the selected configuration and documentation requirements with Captek.
Attributes
Ideal for pharmaceutical companies, hospitals, universities & laboratories- Research & Development focused
- Compact Design
- Powder or Pellets
- Output up to 7,200 capsules/hour
Product reference: CF-S 120C
